| SPECIFICATIONS |
| Voltage |
415V/50Hz/3P |
| Weight |
1500 Kgs |
| Tenon Depth |
5-45 mm |
| Working Workpiece Width |
10-120 mm |
| Working Workpiece Thickness |
10-50 mm |
| Mortise Depth |
5-45 mm |
| Tenon Cutter Speed |
9000-12000 r/min |
| Tenon Motor Power |
5.5 kw / 7.5 HP |
| Model of Mortise Drill Chuck |
Er 25 |
| Mortise Cutter Diameter |
4-16 mm |
| Mortise Cutter Speed |
12000-18000 r/min |
| Motor Power of Mortise Cutter |
3.7 kw / 5 HP |
| Motor Power of Mortise Cutter |
3.7 kw / 5 HP |
| Y Axis Motor |
1 kw / 1.3 HP |
| Tenon Cutter Diameter |
30 mm |
| Cutter Disc Diameter |
130 x 90 mm |
| Total Power |
12 Kw / 16 HP |
| Air Pressure |
6 Bar |
| Suction Hood Diameter |
2 x 100 mm (4 inchx2) |
| Dust Extraction Capacity |
1700M3 /h |
| Overall Dimensions |
2160 x 1080 x 1650 mm(LxWxH) |
