| SPECIFICATIONS |
|
Automation Grade |
Automatic |
| Glue Tank Capacity |
3 kgs |
| Working Pressure |
6 Bar |
| Voltage |
420V / 50C / 3P |
| Voltage |
420V / 50C / 3P |
| Minimum Width of the Panel |
60 mm |
| Minimum Length of the Panel |
150 mm |
| Minimum Thickness of the Panel |
10 mm |
| Maximum Thickness of the Pane |
60 mm |
| Edge Dimensions in Strips |
0.4 – 3 mm |
| Feed Speed |
15,18,23 m/min |
| Power of End Trimming Unit |
0.37 kw x 2 |
| Power of Top and Bottom Trimming Units |
0.73 kw x 2 |
| Power of Corner Trimming Unit |
0.73 kw x 2 |
| Edge Scraping Unit |
Numerical Digital Readout |
| Spraying |
By Pneumatic |
| Buffing Unit 2 Motors With Cloth Disc |
0.37 kw x 2 & Dia 150 mm |
| Conveyor Motor |
3.7 kw |
| Beam Lifting Motor |
0.37 kw |
| Suction Hood Diameter |
4 inch x 4 |
| Installed Power |
11.16 kw |
| Gross Weight |
1772 kgs |
| Net Weight |
1740 kgs |
| Packing Size |
5300 x 1000 x 680 mm |
