16 inch Multipurpose Thickness Planner
16 inch Multipurpose Thickness Planner
We offer a wide range of 16” multipurpose thickess planner Machine. These machines are in high demand, both in the domestic as well the international markets for cutting of wooden logs and all type of wood pieces. Manufactured using quality raw material and precisely balanced wheels keep it steady and silent while cutting, our products are appreciated for their zero maintenance, sturdy construction and durability.
| SPECIFICATIONS | |
|---|---|
| Feeding Speed | 24 (feet per minute) |
| Surfacing Capacity | 410 mm / 13 1/2 inch |
| Max Planning Width | 405 mm / 16 inch |
| Thickness Capacity | 230 mm / 9 inch |
| Length of Planning Table | 1600 mm / 63 1/2 inch |
| Rebating Capacity | 13 mm / 1/2 inch |
| Length of Thickness Table | 915 mm / 36 inch |
| Cutter Block Speed | 35 rpm |
| Circular Saw Table Size | 457 x 356 mm/ 18 x 14 inch |
| Up Down Movement of Circular Saw Table | 75 mm / 3 inch |
| Max Circular Saw Diameter | 300 mm / 12 inch |
| Power Required | 3 HP / 1440 rpm |
